FrSky RB25S Dual Power and Triple Receiver Redundancy Bus with Advanced Stabilization

FrSky RB25S Dual Power and Triple Receiver Redundancy Bus with Advanced Stabilization הוא מוצר מקורי של FrSky מתוך משפחת FrSky power and redundancy range. העמוד נבנה כדי לעזור לבחור נכון לפי התאמה לדגם, פרוטוקול, מספר ערוצים, מתח עבודה, אביזרים תואמים ותפקיד המוצר במערכת ה-RC.

המוצר מתאים ל-radio receiver installations for RC aircraft, helicopters, gliders and advanced telemetry setups. המידע מוצג בצורה מסודרת עבור לקוח קצה, ללא מחירי ספק וללא הפניה לרכישה מחוץ ל-RC-MODEL.

נקודות חשובות

• The RB-25/RB-25S builds on the success of the previous trusted Redundancy Bus Series by adding new advanced features combined with a compact new design which meets the needs of users who want a flight-safe system built in a smaller size unit.
• Triple Receiver Redundancy & Dual Power Input
• RB-25/RB-25S has been designed to offer both dual-power and triple-receiver redundancy. This provides the user triple receiver signal and telemetry redundancy by adding multiplex ports (RX1-3 IN / S.Port). Dual-power provides a safe and efficient way to power the system with your power sources connected via a pair of standard XT30 connections. The dual-power consumption system is designed to operate in balance mode, where it consumes the power line from either power sources depending on which has the higher voltage.
• The RB-25S offers an ADV Stabilizer function which is an upgrade over the original classical gyroscope stabilization modes. The ADV Stabilizer offers an advanced mode that provides more programmable stabilized channels and flexibility.
• The classical stabilization mode has been enhanced with 5 additional stabilization channels, providing pin mapping to each channel in the multiple flight modes like Stabilization, Auto-Level, Hover, and Knife-Edge with an airplane model.
• In the advanced stabilization mode, all the RB25S output pins are configurable for stabilization and additional advanced features such as File Sharing, Programmable Parameters, and Developer Access, etc.

מפרט מרכזי

• מק"ט מוצר: FRSKY-RB25S-DUAL-POWER-AND-TRIPLE-RECEIVER-REDUNDANCY
• משפחת מוצר: FrSky power and redundancy range
• פרוטוקול / RF: ACCESS, FBUS, S.Port, SBUS
• ערוצים: 1 channels
• מתח: 10V, 5V
• משקל: 26.7g
• (Note: Only the S.Port on the RX1 channel port can be used to upgrade firmware.)
• Dimension: 53*40*16mm (L*W*H)
• Number of Channel Ports: 18 (PWM/FBUS/S.Port/SBUS Out)
• Operating Voltage: 4-10V (Recommend 2S Li batteries)
• Operating Current: ≤185mA@5V / Continuous Current: ≤30A
• Operating Temperature: -20°C~75°C
