T-Motor MN1130 KV45/KV53

  • Brand:T-Motor
  • Product Code:T-MOTOR001532
  • Availability:Availability on request
Prices are intentionally not displayed on the site. Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
Quote quantity Choose the requested quantity, select options/variants if available, and add the item to one combined quote request.

These selections are sent with the SKU, model and quantity so we can check fit and availability.

View quote request 0 Ask about this product

T-Motor MN1130 KV45/KV53 is a T-Motor catalog item in Civilian UAV Motors. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

BrandT-Motor
ModelMN1130 KV45/KV53
Manufacturer SKUT-MOTOR001532

Manufacturer technical and configuration tables

Model No.MN1130Motor SizeΦ120.5*65.9mm
Stator TechnologyImported Silicon Steel Sheet; Anti-Rust treatment; 150℃high Temperature-Resisting CoatingsCopper Wire220℃ High Temperature Resistance
Magnet Level180℃ High Temperature ResistanceCoil Insulation Test1000V Withstand Voltage Test
IPIP45Configuration36N40P
Rotor Dynamic Balance Standard≤30mgBearingImported 6902ZZ
Output Shaft Diameter12mmWire Specification/ LengthEnameled Wire*150mm
Technical Parameters
KV Value45Idle Current (20V)2.0A
Max Power (180s)3218WInternal Resistance38mΩ
Rated Voltage (Lipo)24SPeak Current (180s)132A
Max Thrust57.3kgMotor Weight(Incl. Cable)1740g
Package Weight2140g
KV Value53Idle Current (20V)2.4A
Max Power (180s)2926WInternal Resistance28mΩ
Rated Voltage (Lipo)24SPeak Current128A
Max Thrust52.0kgMotor Weight(Incl. Cable)1742g
Package Weight2120g
Recommended Combinations
MotorMN1130 KV45ESCM200A24S
PropellerNS45x17.5/NS47x18Rated Voltage (Lipo)24S
MotorMN1130 KV53ESCM200A24S
PropellerVZ40x16.1Rated Voltage (Lipo)24S
Technical Parameters
KV Value45Idle Current (20V)2.0A
Max Power (180s)3218WInternal Resistance38mΩ
Rated Voltage (Lipo)24SPeak Current (180s)132A
Max Thrust57.3kgMotor Weight(Incl. Cable)1740g
Package Weight2140g
KV Value53Idle Current (20V)2.4A
Max Power (180s)2926WInternal Resistance28mΩ
Rated Voltage (Lipo)24SPeak Current128A
Max Thrust52.0kgMotor Weight(Incl. Cable)1742g
Package Weight2120g
Recommended Combinations
MotorMN1130 KV45ESCM200A24S
PropellerNS45x17.5/NS47x18Rated Voltage (Lipo)24S
MotorMN1130 KV53ESCM200A24S
PropellerVZ40x16.1Rated Voltage (Lipo)24S
TypePropellerVoltage(V)ThrottleCurrent(A)RPMThrust(gf)Power(W)Efficiency(g/W)Torque(N·m)OperatingTemperature(℃)
MN1130 KV45NS45x17.591.9440%12.68153211903116511.706.34121℃(AmbientTemperature:25)
91.9542%14.41159813017132511.246.92
91.9744%16.16166014135148610.867.49
91.9946%17.97171815288165310.538.07
91.9848%19.93178016433183310.138.70
91.9450%22.2118441777820429.819.39
91.9552%24.7119081911222729.4810.09
91.9854%27.3019692046625119.1910.80
91.9656%29.5620252169727198.9211.47
91.9858%32.4020862302729808.6512.19
92.0160%35.7621482461232908.4013.02
91.9662%38.9822102612335848.1613.84
91.9864%41.9422682762038587.9414.65
91.9566%45.7023222904442037.7515.42
91.9768%49.7223793057545727.5616.23
91.9370%54.2824383214749907.3617.12
91.9780%75.5927074016669526.5821.52
91.9590%97.0729034708489266.1325.28
91.97100%119.33307153475109755.7828.76
MN1130 KV45NS47x1892.0540%15.37152114301141410.117.74HOT(AmbientTemperature:25)
92.0542%17.2415831549815879.778.39
92.0544%19.3716431679817829.429.07
92.0546%21.4017011799319709.149.72
92.0848%23.7017611936121828.8710.46
92.1250%26.4718242088324398.5611.26
92.0652%29.2118872238426898.3212.07
92.0654%32.0819472379229538.0612.86
92.0756%34.9620022515832187.8213.60
92.0558%38.2020602667735167.5914.42
92.0460%41.6921212835138387.3915.34
92.0562%45.4521782997341837.1716.21
92.0664%49.2122333159245306.9717.10
92.0566%53.0422853317848826.8017.97
92.0568%57.0723393481852546.6318.86
92.0870%61.8723953663156976.4319.85
92.0680%85.8826474485579065.6724.56
92.0290%107.5228075142398955.2028.23
92.07100%131.22295957306120814.7431.61
MN1130 KV53VZ40x16.192.0140%13.2818661135212219.295.31110℃(AmbientTemperature:25)
92.0042%14.8419461236513659.065.78
92.0144%16.8220301347815488.716.30
92.0046%18.7521091459517258.466.82
91.9848%21.0121921579819328.187.38
92.0150%23.6422721713121757.888.01
92.1252%26.1823581833424127.608.58
92.0054%28.8324401965426527.419.20
92.0456%31.8025182099929277.189.83
91.9858%35.1725992243832346.9410.52
92.0360%38.7226832402635636.7411.27
92.0062%41.9427582550538596.6111.95
92.0364%46.1128382703742446.3712.68
92.0166%49.8529132848845866.2113.39
92.0268%54.0629903007749746.0514.17
92.0270%58.8030713184654105.8914.99
92.0480%84.6934334026377955.1719.07
92.0090%109.25370147354100514.7122.54
92.00100%128.04386952064117804.4224.86
Notes: Motor temperature is the motor surface temperature aftering running on 80% for 10 min. (Based on T-MOTOR test bench(es), all data are for reference only. T-MOTOR reserves the right of final interpretation. )
