T-Motor A14-18S

  • Brand:T-Motor
  • Product Code:T-MOTOR001460
  • Availability:Availability on request
Prices are intentionally not displayed on the site. Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
Quote quantity Choose the requested quantity, select options/variants if available, and add the item to one combined quote request.

These selections are sent with the SKU, model and quantity so we can check fit and availability.

View quote request 0 Ask about this product

T-Motor A14-18S is a T-Motor catalog item in Integrated Propulsion Systems. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

BrandT-Motor
ModelA14-18S
Manufacturer SKUT-MOTOR001460

Manufacturer technical and configuration tables

Model No.A14-18S KV49.6Tube Size50mm
SetupA14-18S (Motor)+18S FOC 150A (ESC)+MF56P(Prop)Wire Material,Wire Gauge, ColorPower Wires: 10#AWG Red & BlackSignal Wires: 5P Teflon
RecommendedBattery18S (LiPo)Wire Length1550±10mm
Rated Thrust25~27kgWeight4355±2%g (Incl. Wires+Prop)
Efficiency AtRated Thrust9.1g/W (25kg)IPIPX6
Max Thrust59kgRecommended Ambient Temperature-30~50℃
Motor Specs
Stator Size138*5mmKV49.6
ESC Specs
Throttle Range1100~1940us (Fixed)Max Voltage75V
ProtocolDRONE CAN、UAV CAN、CUBE CANPeak Current (For A Short Time)150A(OpenEnvironmentAndTemperature≤60℃)
Control MethodPWM/CANBECNO
Prop Specs
Model No.MF56P (Polymer Folding)56 Inch (1424mm)
Motor Specs
Stator Size138*5mmKV49.6
ESC Specs
Throttle Range1100~1940us (Fixed)Max Voltage75V
ProtocolDRONE CAN、UAV CAN、CUBE CANPeak Current (For A Short Time)150A(OpenEnvironmentAndTemperature≤60℃)
Control MethodPWM/CANBECNO
Prop Specs
Model No.MF56P (Polymer Folding)56 Inch (1424mm)
TypeVoltage(V)Throttle(%)Current(A)Thrust(gf)Torque(N·m)RPMMotorEfficiency(%)OverallEfficiency(gf/W)OperatingTemperature(℃)
A14-18S KV49.6+18S FOC 150A+MF56P69V3012.14109116.44101581.6013.00165(Ambient Temperature:33.8)
3517.30140438.37114083.6011.80
4023.871766810.55127585.6010.70
4531.662148712.85141086.909.80
5040.742554615.30154588.209.10
5551.212978817.87166588.508.50
6063.713432320.73177588.407.90
6577.853888823.60189688.107.30
7094.244372626.69200787.206.80
75112.034853029.77209085.506.40
80126.905221132.08220085.806.10
85138.015475233.76223884.505.80
90149.585753335.39229884.205.70
95161.135939236.86232882.705.50
100160.695921036.77233482.905.50

Product inquiry

Availability, price, package contents and hardware revision are confirmed on inquiry. This listing does not assert local stock, a delivery date or official distributor status. Confirm voltage, connectors, firmware and operating requirements before use.
