T-Motor HEP-L 34*11.5 HEP-L 34*11.5 High-Performance Ultra-Light Rotor Propellers

  • Brand:T-Motor
  • Product Code:T-Motor AZP23010016
  • SKU:AZP23010016
  • Availability:Availability on request
Prices are intentionally not displayed on the site. Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
Quote quantity Choose the requested quantity, select options/variants if available, and add the item to one combined quote request.

These selections are sent with the SKU, model and quantity so we can check fit and availability.

View quote request 0 Ask about this product

T-Motor HEP-L 34*11.5 HEP-L 34*11.5 High-Performance Ultra-Light Rotor Propellers is a T-Motor catalog item in Civilian UAV Propellers. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

BrandT-Motor
ModelHEP-L 34*11.5 HEP-L 34*11.5 High-Performance Ultra-Light Rotor Propellers
Manufacturer SKUAZP23010016

Manufacturer technical and configuration tables

ModelMotor CompatibilityRecommendedVoltageRecommended TakeoffWeight for Quadcopter
HEP-L 14*5.1MN4004 KV4006S2.5kg
HEP-L 15*5.5MN4006 EVO KV3806S3kg
HEP-L 16*6MN4006 EVO KV3806S3.5kg
HEP-L 17*6.6MN5006 KV3006S4kg
HEP-L 18*6.7MN5008 KV17012S6kg
HEP-L 18*6.7MN5008 KV3406S6kg
HEP-L 19*6.8MN5008 KV3406S6kg
HEP-L 20*7MN501 KV3006S6kg
HEP-L 21*7MN6007 II KV16012S7kg
HEP-L 21*7MN6007 II KV3206S7kg
HEP-L 22*7.2MN6007 II KV16012S7kg
HEP-L 22*7.2MN6007 II KV3206S7kg
HEP-L 24*7.8MN7005 KV11512S6.5kg
HEP-L 24*7.8MN7005 KV2306S6.5kg
HEP-L 26*8.8MN701S KV13512S15kg
HEP-L 28*9U8II PRO KV10012S12kg
HEP-L 28*9U8II Lite KV10012S12kg
HEP-L 29*11U8II PRO KV10012S13kg
HEP-L 29*11U8II Lite KV10012S13kg
HEP-L 30*10.5U8Lite L KV9512S13kg
HEP-L 32*11MN1005 V2.0 KV9012S14kg
HEP-L 32*11MN1005 V2.0 KV10012S18kg
HEP-L 34*11.5MN1010 KV9012S18kg
HEP-L 36*12MN1010 KV9012S20kg
Diameter (Inch)34 (868.1mm)Common Thrust Range (kg)3.8~6.5
Pitch (Inch)11.5(292.1mm)Common SpeedRange (RPM)1500~2200
AverageSingleBlade Weight (g)93MaterialResin-BasedCarbonFiberComposite+PMIFoamCore
RecommendedMax RPM (RPM)3830Suface TreatmentMatte
RecommendedMax Thrust (kg)26TypeOne-Piece Straight Propeller
Limit RPM (RPM)4300ApplicationLong Endurance Multi-Rotor UAV
Limit Thrust (kg)33Connections &DimensionsFlange Mount, Ø10mm Center Hole, Ø23mm Bolt Circle, With 4*Ø3mm Mounting Holes&Ø31mm Bolt Circle, With 4*Ø4mm
Recommendations
Recommended Solution: MN1010 KV90+ALPHA 120A 12S
Recommendations
Recommended Solution: MN1010 KV90+ALPHA 120A 12S
Ambient Temperature 22 °CAltitude 25 mRPMTorque(N·m)Thrust(gf)OutputPower(W)Effciency(gf/W)
15001.553830243.8315.71
17001.984904352.7113.90
19002.476134491.7012.48
21003.027521664.6311.32
23003.639064875.3410.35
25004.31107631127.669.54
27005.04126191425.428.85
29005.84146311772.478.25
31006.69168002172.637.73
33007.61191252629.737.27
35008.59216063147.616.86
37009.63242443730.116.50
390010.73270384381.066.17
410011.89299885104.295.88
430013.11330955903.635.61
Important Notes: Data may vary under different testing standards due to factors such as equipment, methodology, and environment.Ensure compatibility between the propeller mounting holes and motors. Refer to the drawing above for details.

Product inquiry

Availability, price, package contents and hardware revision are confirmed on inquiry. This listing does not assert local stock, a delivery date or official distributor status. Confirm voltage, connectors, firmware and operating requirements before use.
