T-Motor HEP-S 42*16 HEP-S Series 42*12 High-Performance Heavy-Lift Carbon Fiber Propellers T-Motor HEP-S 42*16 HEP-S Series 42*12 High-Performance Heavy-Lift Carbon Fiber Propellers T-Motor HEP-S 42*16 HEP-S Series 42*12 High-Performance Heavy-Lift Carbon Fiber Propellers T-Motor HEP-S 42*16 HEP-S Series 42*12 High-Performance Heavy-Lift Carbon Fiber Propellers T-Motor HEP-S 42*16 HEP-S Series 42*12 High-Performance Heavy-Lift Carbon Fiber Propellers
15

T-Motor HEP-S 42*16 HEP-S Series 42*12 High-Performance Heavy-Lift Carbon Fiber Propellers

  • Brand:T-Motor
  • Product Code:T-Motor AZP20010018
  • SKU:AZP20010018
  • Availability:Availability on request
Prices are intentionally not displayed on the site. Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
Quote quantity Choose the requested quantity, select options/variants if available, and add the item to one combined quote request.

These selections are sent with the SKU, model and quantity so we can check fit and availability.

View quote request 0 Ask about this product

T-Motor HEP-S 42*16 HEP-S Series 42*12 High-Performance Heavy-Lift Carbon Fiber Propellers is a T-Motor catalog item in Civilian UAV Propellers. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

BrandT-Motor
ModelHEP-S 42*16 HEP-S Series 42*12 High-Performance Heavy-Lift Carbon Fiber Propellers
Manufacturer SKUAZP20010018
RecommendedSolutionMN1123 KV53+M200A 24S/U15 II KV100

Manufacturer technical and configuration tables

Diameter (Inch)42 (1072.4mm)Common Thrust Range (kg)9.7~21.2
Pitch (Inch)16 (406.4mm)Common SpeedRange (RPM)1750~2500
AverageSingleBlade Weight (g)225MaterialResin-BasedCarbonFiberComposite+PMIFoamCore
RecommendedMax RPM (RPM)3640Suface TreatmentGlossy
RecommendedMax Thrust (kg)52TypeOne-Piece Straight Propeller
Limit RPM (RPM)4050ApplicationHeavy-Lift Multirotor Drone
Limit Thrust (kg)65Connections &DimensionsFlange Mount, Ø12mm Center Hole, Ø30mm Bolt Circle, With 4*Ø5mm Mounting Holes
Recommendations
RecommendedSolutionMN1123 KV53+M200A 24S/U15 II KV100
Recommendations
RecommendedSolutionMN1123 KV53+M200A 24S/U15 II KV100
Ambient Temperature: 22℃Altitude: 25mRPMTorque(N·m)Thrust(gf)OutputPower(W)Effciency(gf/W)
16705.1410463898.6011.64
18406.23127961200.4910.66
20107.45153701567.979.80
21808.80181842007.819.06
235010.27212392526.798.41
252011.87245353131.697.83
269013.59280723829.277.33
286015.45318504626.326.88
303017.43358685529.616.49
320019.53401286545.926.13
337021.77446287682.025.81
354024.13493688944.695.52
371026.625435010340.705.26
388029.235957211876.845.02
405031.976503613559.864.80
Important Notes: Data may vary under different testing standards due to factors such as equipment, methodology, and environment.Ensure compatibility between the propeller mounting holes and motors. Refer to the drawing above for details.
