T-Motor HEP-S 32*11 HEP-S Series 32*11 High-Performance Heavy-Lift Carbon Fiber Propellers

  • Brand:T-Motor
  • Product Code:T-Motor AZP20010015
  • SKU:AZP20010015
  • Availability:Availability on request
Prices are intentionally not displayed on the site. Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
Quote quantity Choose the requested quantity, select options/variants if available, and add the item to one combined quote request.

These selections are sent with the SKU, model and quantity so we can check fit and availability.

View quote request 0 Ask about this product

T-Motor HEP-S 32*11 HEP-S Series 32*11 High-Performance Heavy-Lift Carbon Fiber Propellers is a T-Motor catalog item in Civilian UAV Propellers. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

BrandT-Motor
ModelHEP-S 32*11 HEP-S Series 32*11 High-Performance Heavy-Lift Carbon Fiber Propellers
Manufacturer SKUAZP20010015
RecommendedSolutionP80 II KV100/MN1010 KV135/U13 II KV130/U13 II KV65

Manufacturer technical and configuration tables

Diameter (Inch)32 (822.9mm)Common Thrust Range (kg)4.9~10.6
Pitch (Inch)11 (279.4mm)Common SpeedRange (RPM)2130~3100
AverageSingleBlade Weight (g)103MaterialResin-BasedCarbonFiberComposite+PMIFoamCore
RecommendedMax RPM (RPM)4930Suface TreatmentGlossy
RecommendedMax Thrust (kg)30TypeOne-Piece Straight Propeller
Limit RPM (RPM)5510ApplicationHeavy-Lift Multirotor Drone
Limit Thrust (kg)38Connections &DimensionsFlange Mount, Ø4mm Center Hole, Ø12mm Bolt Circle, With 2*Ø3mm Mounting Holes
Recommendations
RecommendedSolutionP80 II KV100/MN1010 KV135/U13 II KV130/U13 II KV65
Recommendations
RecommendedSolutionP80 II KV100/MN1010 KV135/U13 II KV130/U13 II KV65
Ambient Temperature: 22℃Altitude: 25mRPMTorque(N·m)Thrust(gf)OutputPower(W)Effciency(gf/W)
13100.732005100.5319.95
16101.052898177.0416.37
19101.464049292.8713.83
22101.985460457.1311.94
25102.587130678.9610.50
28103.299060967.489.36
31104.09112481331.828.45
34104.99136961781.117.69
37105.98164042324.487.06
40107.08193702971.056.52
43108.26225963729.966.06
46109.55260814610.335.66
491010.93298255621.295.31
521012.41338286771.965.00
551013.99380918071.484.72
Important Notes: Data may vary under different testing standards due to factors such as equipment, methodology, and environment.Ensure compatibility between the propeller mounting holes and motors. Refer to the drawing above for details.
