T-Motor VZ22*7.4

  • Brand:T-Motor
  • Product Code:T-Motor AZP01010029
  • SKU:AZP01010029
  • Availability:Availability on request
Prices are intentionally not displayed on the site. Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
Quote quantity Choose the requested quantity, select options/variants if available, and add the item to one combined quote request.

These selections are sent with the SKU, model and quantity so we can check fit and availability.

View quote request 0 Ask about this product

T-Motor VZ22*7.4 is a T-Motor catalog item in Civilian UAV Propellers. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

BrandT-Motor
ModelVZ22*7.4
Manufacturer SKUAZP01010029

Manufacturer technical and configuration tables

Diameter (Inch)22(558.8mm)MaterialResin-basedCarbonFiberComposite+PMIFoamCore
Pitch (Inch)7.4(188.0mm)Surface TreatmentMatte
AverageSingleblade Weight (g)43TypeOne-Piece Straight Propeller
RecommendedMax RPM (RPM)7350ApplicationVTOL Fixed-Wing UAVs, Multicopter Mode
RecommendedMax Thrust (kg)14.4Connections & DimensionsFlange Mount, Ø6 mm Center Hole, Ø12 mm Bolt Circle, with 2x Ø3 mm Mounting Holes
Limit RPM (RPM)8200RecommendationsRecommended Solution：V605 KV210+FLAME 80A 12S V2.0/VL6011 KV180+V60A/VL6013 KV210+V80A
Limit Thrust (kg)18
Ambient Temperature 22 °CAltitude 25 mRPM(RPM)Torque（N·m)RecommendedThrust（gf）Output Power（W）力Effciency（gf/W）
40000.9463901396.219.85
43001.1034553496.879.16
46001.2765261614.738.56
49001.4646027751.238.02
52001.6676850907.787.55
55001.88577311085.837.12
58002.11986681286.796.74
61002.36796621512.106.39
64002.631107141763.186.08
67002.910118222041.475.79
70003.204129882348.405.53
73003.513142112685.395.29
76003.837154913053.875.07
79004.177168283455.274.87
82004.531182223891.024.68
Important Notes
Data may vary under different testing standards due to factors such as equipment, methodology, and environment.Ensure compatibility between the propeller mounting holes and motors. Refer to the drawing above for details.
