T-Motor VZ29*11
Prices are intentionally not displayed on the site.
Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
T-Motor VZ29*11 is a T-Motor catalog item in Civilian UAV Propellers. Review the model details below and request compatibility and supply information for civilian use.
Model specifications
| Brand | T-Motor |
|---|---|
| Model | VZ29*11 |
| Manufacturer SKU | AZP01010021 |
Manufacturer technical and configuration tables
| Diameter (Inch) | 29(736.6mm) | Material | Resin-basedCarbonFiberComposite+PMIFoamCore |
| Pitch (Inch) | 11(279.4mm) | Surface Treatment | Matte |
| AverageSingleblade Weight (g) | 89 | Type | One-Piece Straight Propeller |
| RecommendedMax RPM (RPM) | 5800 | Application | VTOL Fixed-Wing UAVs, Multicopter Mode |
| RecommendedMax Thrust (kg) | 28.8 | Connections & Dimensions | Flange Mount, Ø10 mm Center Hole, Ø20 mm Bolt Circle, with 4x Ø3 mm Mounting Holes |
| Limit RPM (RPM) | 6400 | Recommendations | Recommended Solution：VL8022 KV170+V150A/VL1028 KV190+V200A |
| Limit Thrust (kg) | 36 |
| Ambient Temperature 22 °CAltitude 25 m | RPM(RPM) | Torque（N·m) | RecommendedThrust（gf） | Output Power（W） | 力Effciency（gf/W） | |||
| 2200 | 1.35 | 3957 | 311.14 | 12.72 | ||||
| 2500 | 1.71 | 5074 | 446.51 | 11.36 | ||||
| 2800 | 2.13 | 6377 | 623.82 | 10.22 | ||||
| 3100 | 2.62 | 7864 | 849.38 | 9.26 | ||||
| 3400 | 3.17 | 9536 | 1129.49 | 8.44 | ||||
| 3700 | 3.80 | 11393 | 1470.48 | 7.75 | ||||
| 4000 | 4.48 | 13434 | 1878.65 | 7.15 | ||||
| 4300 | 5.24 | 15661 | 2360.31 | 6.64 | ||||
| 4600 | 6.07 | 18072 | 2921.78 | 6.19 | ||||
| 4900 | 6.96 | 20668 | 3569.35 | 5.79 | ||||
| 5200 | 7.91 | 23449 | 4309.35 | 5.44 | ||||
| 5500 | 8.94 | 26415 | 5148.09 | 5.13 | ||||
| 5800 | 10.03 | 29566 | 6091.87 | 4.85 | ||||
| 6100 | 11.19 | 32901 | 7147.00 | 4.60 | ||||
| 6400 | 12.41 | 36421 | 8319.80 | 4.38 | ||||
| Important Notes | ||||||||
| Data may vary under different testing standards due to factors such as equipment, methodology, and environment.Ensure compatibility between the propeller mounting holes and motors. Refer to the drawing above for details. | ||||||||
Product inquiry
Availability, price, package contents and hardware revision are confirmed on inquiry. This listing does not assert local stock, a delivery date or official distributor status. Confirm voltage, connectors, firmware and operating requirements before use.
- Original manufacturer model information
