T-Motor ALPHA 80A 12S Multi-Rotor Drone ESC

  • Brand:T-Motor
  • Product Code:T-Motor AWT02010003
  • SKU:AWT02010003
  • Availability:Availability on request
Prices are intentionally not displayed on the site. Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
Quote quantity Choose the requested quantity, select options/variants if available, and add the item to one combined quote request.

These selections are sent with the SKU, model and quantity so we can check fit and availability.

View quote request 0 Ask about this product

T-Motor ALPHA 80A 12S Multi-Rotor Drone ESC is a T-Motor catalog item in ESCs & Motor Controllers. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

BrandT-Motor
ModelALPHA 80A 12S Multi-Rotor Drone ESC
Manufacturer SKUAWT02010003

Manufacturer technical and configuration tables

Size88.5*36.6*19mm（L*W*H）Power CableSilicone wire-red/black-12AWG-180MM
Weight(Incl. cables)110gSignal CablePVC flat cable-30 core wires--2-450MM (white, blank, black/JP 3P male connector)
Motor CableSilicone wire-deep orange-14AWG-110MM*3PCSprogramming CablePVC flat cable-30 core wires--3-50MM (black, red, white/JP 3P male connector)
Support Voltage(12S)18-52.2VBECNO
Con. Current80AThrottle Pos. Range1100-1940μs
Peak Current(10s)100AThrottle Refresh Frequency500Hz
Standby Consumption≤50mAThrottle Response Speed300ms
Support Voltage(12S)18-52.2VBECNO
Con. Current80AThrottle Pos. Range1100-1940μs
Peak Current(10s)100AThrottle Refresh Frequency500Hz
Standby Consumption≤50mAThrottle Response Speed300ms

Product inquiry

Availability, price, package contents and hardware revision are confirmed on inquiry. This listing does not assert local stock, a delivery date or official distributor status. Confirm voltage, connectors, firmware and operating requirements before use.
