T-Motor MN1320 KV49

  • Brand:T-Motor
  • Product Code:T-Motor AWD01010265
  • SKU:AWD01010265
  • Availability:Availability on request
Prices are intentionally not displayed on the site. Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
Quote quantity Choose the requested quantity, select options/variants if available, and add the item to one combined quote request.

These selections are sent with the SKU, model and quantity so we can check fit and availability.

View quote request 0 Ask about this product

T-Motor MN1320 KV49 is a T-Motor catalog item in Civilian UAV Motors. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

BrandT-Motor
ModelMN1320 KV49
Manufacturer SKUAWD01010265

Manufacturer technical and configuration tables

Model No.MN1320Motor SizeΦ150*56mm
Stator Technology150℃ High Temperature-Resisting CoatingsCopper Wire220℃ High Temperature Resistance
Magnet Level180℃ High Temperature ResistanceCoil Insulation Test1000V Withstand Voltage Test
IPIP45Configuration36N42P
Rotor Dynamic Balance Standard≤30mgBearingImported 6904ZZ
Output Shaft Diameter/Wire Specification/ LengthEnameled Wire*150mm
Technical Parameters
KV Value49Idle Current (20V)3.2A
Max Power (180s)2900WInternal Resistance20.5mΩ
Rated Voltage (Lipo)24SPeak Current150A
Max Thrust58kgMotor Weight(Incl. Cable)2070g
Package Weight2640g
Recommended Combinations
MotorMN1320 KV49ESCM200A24S
PropellerNS45x17.5Rated Voltage (Lipo)24S
Technical Parameters
KV Value49Idle Current (20V)3.2A
Max Power (180s)2900WInternal Resistance20.5mΩ
Rated Voltage (Lipo)24SPeak Current150A
Max Thrust58kgMotor Weight(Incl. Cable)2070g
Package Weight2640g
Recommended Combinations
MotorMN1320 KV49ESCM200A24S
PropellerNS45x17.5Rated Voltage (Lipo)24S
TypePropellerVoltage(V)ThrottleCurrent(A)RPMThrust(gf)Power(W)Efficiency(g/W)Torque(N·m)OperatingTemperature(℃)
MN1320KV49NS45x17.591.9440%14.0115531237812889.616.5493℃(AmbientTemperature:25)
91.9542%16.1716331373914869.247.26
91.9844%18.5917121518217108.888.03
91.9846%21.1217871666319438.588.80
91.9848%23.9818651826122068.289.64
91.9950%27.3519462001525167.9610.57
92.0052%30.7920232174328327.6811.52
91.9854%34.5020992344231737.3912.44
91.9856%38.1521702513035097.1613.35
91.9458%42.3822422701538976.9314.37
91.9460%47.0123182898643226.7115.44
91.9362%51.6923893098447516.5216.51
91.9464%57.0624583298552466.2917.60
91.9566%61.8225213495956846.1518.68
91.9568%67.1325873701061736.0019.80
91.9070%73.6326533910767675.7820.98
91.9180%90.4928304448083235.3424.07
91.9390%126.87310854596116624.6829.84
91.81100%148.96321858958136754.3132.44
Notes: Motor temperature is the motor surface temperature aftering running on 80% for 10 min. (Based on T-MOTOR test bench(es), all data are for reference only. T-MOTOR reserves the right of final interpretation. )
