Servo selection: torque, speed, gears and voltage
How to select servos for trainers, sport aircraft, large models, cars and boats without under-sizing a control surface.
DS6125E
Prices are intentionally not displayed on the site.
Contact RC-MODEL for current availability, technical fit, compatible accessories and a formal quote.
DS6125E from MKS Servo is organized here as a practical RC-MODEL product page with customer-focused selection guidance, structured specifications and product imagery. Supplier pricing and external buying routes are intentionally excluded from the storefront.
This item is intended for gliders, F3X/F3K wings, tails and compact installations. MKS servos are a strong fit for pilots and RC drivers who care about accurate centering, fast response, reliable gear trains and confident control under load.
Motor: Japanese-made Coreless Motor. Gear train: Metal Alloy Gear. Voltage range: 4.8V ~ 7.0V DC Volt. Before installation, check receiver/BEC voltage, gyro or radio compatibility, servo bay dimensions, servo arm fit and the mechanical load of the model.
- Torque: 3.25
- Speed: 0.053
- Voltage: 4.8V ~ 7.0V DC Volt
- Dimensions: 23 x 12 x 27.25 mm
- Weight: 21.21 g
Key Specifications
| Product Code | S0015004 |
|---|---|
| Servo dimensions | Micro |
| Servo type | Digital |
| Programmable | No |
| Torque at 4.8V [kg∙cm] | 2.58 |
| Torque at 6.0V [kg∙cm] | 3.25 |
| Speed at 4.8V [s/60st.] | 0.066 |
| Speed at 6.0V [s/60st.] | 0.053 |
| Working Voltage | 4.8V ~ 7.0V DC Volt |
| Working Frequency | 1500μs / 333Hz |
| Dead Band | 0.0008 ms (Default) |
| Bearing | 2* Ball Bearing |
| Gear | Metal Alloy Gear |
| Motor | Japanese-made Coreless Motor |
| Length [mm] | 23 |
| Width [mm] | 12 |
| Height [mm] | 27.25 |
| Weight [g] | 21.21 |
Relevant RC Academy guides
Learn before you buy
These guides explain the setup, safety checks and accessory choices that usually matter for this product type.
Which servo fits each RC aircraft type?
A buying table for matching servo size, torque, speed, gear type and voltage to trainers, gliders, 3D aircraft, EDF jets and Giant Scale models.
How to install servos and linkages correctly
Mechanical setup guide for servo arms, linkage angles, throw, control horns, neutral position and radio setup after geometry is correct.
How to set Dual Rates and Expo on an RC transmitter
Make an aircraft calmer for beginners by setting low rates, high rates and expo without hiding mechanical setup problems.
How to set failsafe correctly on an RC aircraft
Failsafe setup for electric and fuel aircraft: throttle behavior, receiver signal loss, switch positions and safe verification before flight.
| Technical Specifications | |
| Servo dimensions | Micro |
| Servo type | Digital |
| Programmable | No |
| Torque at 6.0V [kg∙cm] | 3.25 |
| Speed at 6.0V [s/60st.] | 0.053 |
| Length [mm] | 23 |
| Width [mm] | 12 |
| Height [mm] | 27.25 |
| Weight [g] | 21.21 |
| Intended for | Gliders |
| Product Code | S0015004 |
| Manufacturer | MKS Servo |
| Source Series | Glider Series |
| Torque at 4.8V [kg∙cm] | 2.58 |
| Speed at 4.8V [s/60st.] | 0.066 |
| Working Voltage | 4.8V ~ 7.0V DC Volt |
| Working Frequency | 1500μs / 333Hz |
| Dead Band | 0.0008 ms (Default) |
| Bearing | 2* Ball Bearing |
| Gear | Metal Alloy Gear |
| Motor | Japanese-made Coreless Motor |
