Propeller 28x12 CW 2B TH
Propeller 28x12 CW 2B TH is a Carbon gas pusher propeller from Mejzlik Propellers, prepared for RC-MODEL customers with practical fitment guidance, structured specifications, product imagery and no supplier pricing.
Recommended use
Use this item for gas engine pusher propulsion. The key size reference is 28x12 inches. Confirm diameter, pitch, rotation, blade count, hub/backplate fitment, engine or motor load, RPM range and airframe clearance before ordering.
What to confirm before ordering
Carbon propeller selection should consider the complete propulsion setup: motor or engine power, battery voltage or displacement, expected RPM, thrust requirement, mounting pattern, balancing and safety margin. RC-MODEL can help verify the correct part when you provide the aircraft/UAV setup and part number.
Technical data: no matching public datasheet was listed for reference 22812003.
Key details
- Manufacturer: Mejzlík Propellers s.r.o
- Brand: MEJZLIK
- Part No.: 22812003
- Product Type: Carbon gas pusher propeller
- Application: Gas engine pusher propulsion
- Availability: OTS
- Source Catalog: MEJZLIK 2025 Carbon Fiber Propellers design list
- Catalog Revision: 19.9.23
- Diameter (in): 28
- Pitch (in): 12
- Diameter (mm): 711.2
- Blade Count: 2
- Rotation: CW
- Construction: Carbon fiber composite propeller from MEJZLIK
- Series / Variant: TH
- Datasheet: Not listed in MEJZLIK public data page
- Performance Data: Not listed in MEJZLIK public data page
- Video: MEJZLIK manufacturing technology video embedded
Manufacturing technology video
Reference part number: 22812003. This page is part of the official MEJZLIK catalog coverage at RC-MODEL.
Relevant RC Academy guides
Learn before you buy
These guides explain the setup, safety checks and accessory choices that usually matter for this product type.
How to choose the right propeller for an RC aircraft
Diameter, pitch, motor load, current measurement and how propeller choice changes thrust, speed, efficiency and heat.
How to choose the right ESC for an RC aircraft
ESC selection by maximum current, voltage, BEC, safety margin, cooling, connector choice and the real load from motor and propeller.
How to measure current draw with a Watt Meter
A step-by-step safety guide for measuring amps, watts and voltage sag so customers avoid overheating motors, ESCs and LiPo batteries.
How to prevent motor and propeller vibration
A safety and performance guide to propeller balance, spinner fit, bent shafts, motor mounts, firewall checks and protecting electronics from vibration.
| Technical Specifications | |
| Manufacturer | Mejzlík Propellers s.r.o |
| Brand | MEJZLIK |
| Part No. | 22812003 |
| Product Type | Carbon gas pusher propeller |
| Application | Gas engine pusher propulsion |
| Availability | OTS |
| Source Catalog | MEJZLIK 2025 Carbon Fiber Propellers design list |
| Catalog Revision | 19.9.23 |
| Diameter (in) | 28 |
| Pitch (in) | 12 |
| Diameter (mm) | 711.2 |
| Blade Count | 2 |
| Rotation | CW |
| Construction | Carbon fiber composite propeller from MEJZLIK |
| Datasheet | Not listed in MEJZLIK public data page |
| Performance Data | Not listed in MEJZLIK public data page |
| Video | MEJZLIK manufacturing technology video embedded |
| Series / Variant | TH |
