Holybro Tekko32 F4 45A ESC (AM32)

Holybro Tekko32 F4 45A ESC (AM32) is a Holybro catalog item in ESCs & Motor Controllers. Review the model details below and request compatibility and supply information for civilian use.

Model specifications

Manufacturer technical notes

Tekko32 F4 45A ESC is the latest AM32 ESC from HolyBro. The Tekko32 ESC runs in conjunction with an ARM 32-bit compatible F4 MCU. It can run input signals with lower latency, at faster rates, smooths out the RPM band, is capable of both voltage and current monitoring and limiting, as well as offering customization of the brake on stop force. The Tekko32 ESC has a lot of room to grow and a wide compatibility range with future products.

F4 MCU support Dshot1200 up to 32kHz

AM32 firmware (target: AM32_TEKKO32_F421)

Small size & low weight

Auto Timing Feature

Built-in Current sensor

Smooth Response

2-6s LIPO input

Ext. cap recommended for 6s (330uf 35v for 6s usage.)

Size: 17.3*34.3*4.5mm

Tekko32 F4 45A ESC *1Electrolytic capacito: 330uF 35v *124AWG 100mm Black wire *124AWG 100mm White wire *124AWG 100mm Blue wire *116AWG 100mm Red wire *116AWG 100mm Black wire *1

Tekko32 F4 45A ESC SPEC

AM32 ESC Firmware Overview AM32 ESC Configurator

Manufacturer catalog configurations

Product inquiry

Availability, price, package contents and hardware revision are confirmed on inquiry. This listing does not assert local stock, a delivery date or official distributor status. Confirm voltage, connectors, firmware and operating requirements before use.

• Original manufacturer model information
• Manufacturer documentation
