Why choose PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2 through RC-MODEL?
PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2 is an RC product from Phoenix Model. This page focuses on what an end customer needs: fit, use cases, specifications and imagery, without prices or outbound supplier detours.
Fit and use
PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2 fits customers looking for Phoenix Model items in Scale Aircraft, with RC-MODEL support for choosing the right configuration.
- Relevant category: Scale Aircraft
- Product identification for inquiry: model PH238-MESSERCHMITT / SKU PH238-MESSERCHMITT
Key details
- Packing: BOX DIMENSION - 1294mm X 515mm X 288mm (L x W x H)
- Length: 1609mm (63.3 in)
- Wingspan: 1820mm (71.7 in)
- Flying weight: 5000 – 5200 g
- Gear type: Electric Retract Gear (included) with controller box (included).
- Spinner size: 115mm (included)
Before ordering
- Confirm dimensions, power system, radio compatibility or material size before purchase.
- Ask us to match required accessories, adhesives, hardware, batteries or replacement parts.
- RC-MODEL helps with fit checks, availability, compatible accessories and a formal quote in Israel.
PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2
PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2 is presented as an information-rich scale RC aircraft from Phoenix Model for RC-MODEL customers who want clear product data, official imagery, and practical comparison details without storefront pricing.
Key Specifications
- Wingspan: 1820mm (71.7 in)
- Length: 1609mm (63.3 in)
- Flying weight: 5000 – 5200 g
- Wing area: 56 dm2
- Wing loading: 89 g/dm2
- Gear type: Electric Retract Gear (included) with controller box (included).
- Spinner size: 115mm (included)
- Radio: 8 channel minimum (not included)
- Servo: 8 Standard servo: 2 aileron; 2 flap; 2 elevator; 1 rudder; 1 throttle (not included)
- Propeller: Suit with your engine
- Engine: 20-26cc Gas Engine (not included)
- Motor: brushless outrunner 1500-1800 W, 450 KV (not included); RIMFIRE 1.20 (not included)
Recommended Use
This catalog page is written for pilots, builders, racers, and RC hobby users comparing scale aircraft products. It highlights the manufacturer, model identity, application, and measurable details that matter when choosing compatible RC equipment.
Product-specific guides
Buying and setup guides for PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2
Use these notes to choose compatible accessories, plan assembly, order sensible spares and ask the right questions before buying PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2.
Compatibility guide
Compatibility and accessories
Before ordering PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2, match it to your setup, the Phoenix Model brand context and the exact product code PH238-MESSERCHMITT. These are the first points we would confirm with you.
- Specification to verify: Packing - BOX DIMENSION - 1294mm X 515mm X 288mm (L x W x H)
- Specification to verify: Length - 1609mm (63.3 in)
- Battery cell count, capacity and physical tray size
- Motor, ESC, propeller and servo compatibility
- CG range, receiver channels and required pilot level
Find matching products
Assembly guide
Correct setup and adjustment
For PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2, installation quality matters as much as the product itself. Use the Phoenix Model / PH238-MESSERCHMITT identification to plan tools, setup order and final checks.
- Dry fit wing, tail, landing gear and canopy before glue
- Check hinge security, servo direction, throws and failsafe
- Balance CG with the real flight battery installed
Find matching products
Spare parts guide
Spare parts to prepare
For PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2, useful spares are the parts most likely to stop a flying, sailing or workshop day. Keep the exact code Phoenix Model ready so RC-MODEL can match compatible items from PH238-MESSERCHMITT where available.
- Propellers, spinner, wheel or landing gear parts
- Hinges, control horns, servo arms and pushrods
- Battery straps, screws, adhesives and field tools
Find matching products
Upgrade guide
Useful upgrade options
Upgrade PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2 only where it improves reliability, control, cooling, power margin or serviceability. We compare the current Phoenix Model setup with the target use of PH238-MESSERCHMITT before recommending parts.
- Metal gear servos where load or landing shock is high
- ESC/BEC margin, telemetry and clean cooling airflow
- Propeller and battery choices matched with current measurement
Find matching products
Questions and answers
Questions before buying
Before choosing PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2, send RC-MODEL the model code Phoenix Model, your existing equipment and the way you plan to use it. That lets us answer with a practical fit recommendation instead of a generic answer.
- Expected flight time and recommended battery range
- CG location, control throws and glue type
- Runway length, wind tolerance and experience level
Ask RC-MODEL
Relevant RC Academy guides
Learn before you buy
These guides explain the setup, safety checks and accessory choices that usually matter for this product type.
Building
A general ARF assembly workflow for many aircraft: dry fit, hinges, servo installation, power setup, CG, control checks and first-flight preparation.
Servos
How to select servos for trainers, sport aircraft, large models, cars and boats without under-sizing a control surface.
Setup
One of the most important setup guides: find the CG, install the flight battery, balance the aircraft and avoid nose-heavy or tail-heavy surprises.
Maintenance
A repeatable inspection routine for control direction, radio range, failsafe, battery, fasteners, propeller, CG and field readiness.
Flying
Ground checks, takeoff planning, trim passes, battery timing and first landing strategy for a new or repaired RC aircraft.
Product video
Embedded video for convenient viewing directly on the product page.
Product questions
Is PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2 suitable for my RC setup?
PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2 fits customers looking for a Phoenix Model product in Scale Aircraft. Before ordering, send us your model type, dimensions, radio or power setup so we can confirm the correct fit.
What should I include when asking about PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2?
Include product code or model PH238-MESSERCHMITT, intended use, desired quantity, items you already have and any size or weight limits. That helps us answer faster and more accurately.
Can RC-MODEL match accessories and parts for PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2?
Yes. RC-MODEL can help match accessories, adhesives, hardware, batteries, replacement parts and supporting equipment so the product fits your setup properly.
Which battery, CG and setup checks are important for PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2?
For PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2, verify the recommended battery range, physical tray size, CG, control direction, control throws and failsafe before the first flight. Use the exact model code PH238-MESSERCHMITT when asking for a fit check.
Which spare parts should I order with PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2?
For PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2, consider propellers, landing gear parts, hinges, control horns, servo arms, screws, battery straps and suitable adhesives. Exact spares should be matched to model PH238-MESSERCHMITT.
Which upgrades are useful for PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2?
Useful upgrades for PH238-MESSERCHMITT Bf 109 72'' W/Electric Retract 20cc ARF V2 may include stronger servos, better ESC/BEC margin, telemetry, a tested propeller choice or batteries matched to the real current draw of PH238-MESSERCHMITT.
| Technical Specifications |
| Product Type |
ARF aircraft model |
| Length |
1609mm (63.3 in) |
| Motor |
brushless outrunner 1500-1800 W, 450 KV (not included); RIMFIRE 1.20 (not included) |
| Wingspan |
1820mm (71.7 in) |
| Flying weight |
5000 – 5200 g |
| Wing area |
56 dm2 |
| Gear type |
Electric Retract Gear (included) with controller box (included). |
| Spinner size |
115mm (included) |
| Feature |
- Designed for compatibility with both GP and EP flight - Electric Retract With CNC Suspension Metal included - Full-depth cockpit and instrument panel and pilot included - Removable Top Hatch Canopy for easy change lipo battery and set up radio - Strong Ligh... |
| Colour chart |
Not update... |
| Packing |
BOX DIMENSION - 1294mm X 515mm X 288mm (L x W x H) |
| Wing loading |
89 g/dm2 |
| Servo |
8 Standard servo: 2 aileron; 2 flap; 2 elevator; 1 rudder; 1 throttle (not included) |
| Propeller |
Suit with your engine |
| Engine |
20-26cc Gas Engine (not included) |
| Experience level |
Intermediate |
| Plane type |
Fighter aircraft |
| Lipo cell |
6 cells (not included) |
| Esc |
80-100A (not included) |
| Radio |
8 channel minimum (not included) |
